Chandler ramada and pergola permits

Installation is done by a licensed Arizona contractor.

Price your project

Typical installed range: $12,000–$34,000

Call (602) 557-3625

Installation is done by a licensed Arizona contractor.

Chandler classes a shade structure that’s open on the sides, with a roof or lattice cover, as an open-air ramada, and its chart marks a building permit as needed at any size. That’s stricter than the 200-square-foot line most Valley cities use.

Why Chandler calls a pergola a ramada

Chandler’s Detached Buildings & Structures Chart treats a structure open on the sides that supports a roof or lattice-type cover, built mainly for shade, as an open-air ramada. For that column the chart’s answer to “building permit needed” is “YES – check with Building Plan Review staff for requirements,” with no size below which it’s exempt.

The chart also has a separate column for shade structures open on all sides, so ask the city which column your design falls under before you order. Chandler’s no-permit limit for a storage shed is lower than its neighbors’ too: 120 square feet and 7 feet tall, with no electricity, gas or water.

Setbacks measured from the roof edge

Chandler measures a ramada’s setbacks from the outside edge of its roof, not from its posts:

  • 5 feet from the side and rear property lines, measured from the edge of the roof overhang, eave or beam.
  • No overhang into that 5 feet. Because the measurement starts at the roof edge, the chart allows zero overhang into the setback.
  • 1 foot between roofs. The edge of the ramada’s roof has to stay at least 1 foot from the edge of the house’s roof.
  • Behind the front of the house, in the side or rear yard.

On a louvered pergola, ask the installer to measure the 5 feet from the outside of the frame and gutter, since that’s the roof’s outer edge.

Plan of a Chandler rear yard corner: a ramada’s dashed roof edge sits 5 feet from the rear and side property lines, because Chandler measures the setback from the edge of the roof overhang, eave or beam and allows no overhang into it; the roof edge stays at least 1 foot from the house’s roof edge; all ramadas together may cover no more than 30 percent of the rear yard and count toward lot coverage. An open-air ramada needs a building permit at any size.
Chandler’s ramada setbacks start at the roof edge, so the posts sit farther in than the 5 ft suggests.

The 30% rear-yard cap, lot coverage and height

All the ramadas on a lot together can take up no more than 30% of the rear yard, and their area also counts toward the zoning district’s maximum lot coverage.

Chandler measures height from grade to the very top of the roof. Its current chart lists separate height limits for open-air ramadas and for shade structures open on all sides, so confirm the one that applies to your design before you settle on a post height. If the home is in a Planned Area Development district, that PAD’s own rules for accessory buildings can apply as well.

The city’s Planner of the Day answers these questions before you apply: 480-782-3050 or pod@chandleraz.gov.

Chandler: questions homeowners ask

Does a small freestanding pergola need a permit in Chandler?

If it’s open on the sides with a roof or lattice cover, Chandler treats it as an open-air ramada, and its chart marks a building permit as needed at any size.

How close to the property line can a ramada be in Chandler?

5 feet from the side and rear property lines, measured from the edge of the roof, with no overhang into that setback, and at least 1 foot from the edge of the house’s roof.

Who answers permit questions before I apply in Chandler?

The Planner of the Day at Development Services: 480-782-3050 or pod@chandleraz.gov.

More answers in the pergola and patio cover FAQ, or see how a request works.

Chandler sources

Checked October 18, 2026. Rules change, so the installer confirms them for your address. Installed prices don’t change at the city line; the cost guides and calculator have the Valley ranges.
